    3-Way VNA Forklift Mobile Robot with 180° Rotation and Side Shift

    3-Way VNA Forklift Mobile Robot with 180° Rotation and Side Shift

    3-Way VNA Forklift Narrow Aisle High-Level Storage Manufacturer
    • Product Introduction
    • Product Parameters

    The 3-way Very Narrow Aisle Forklift FMR features 180° rotation and sideways movement, enabling cargo stacking and picking without vehicle turning. Its core narrow-aisle operation capability drastically saves land use and achieves racking-intensive storage, with a maximum lifting height of 8000mm to meet high-level, narrow-aisle intensive storage demands.

    Features

    •Fork 3-way Rotation, Used in Narrow Aisle

    •Multiple Navigation, Safe & Reliable

    •Custom Deployment, Smart & Efficient

    •High Position Stacking, Increase Storage Capacity

    TECHNICAL PARAMETERS                                                                ●  Standard  ○ Optional    -Not available
    Basic

    Parameters
    Model No. X5-3W10
    Load Capacity kg 1000
    Load Center Distance c(mm) 600
    Weight(ind.battery) kg 6450
    Fork L×W×H 16*e*s(mm) 1220*132*45
    Fork Outside Spacing b5(mm) 580-998
    Fork Inside Spacing b4(mm) 316-734
    Max. Lifting Height h2(mm) 5500(standard)/6000/6500/7000/7500/8000
    Mast Lowered Height h1(mm) 3280(standard)/3490/3700/3910/4120/4320
    Max.Vehicle Height(Navigator Top) h1'(mm) 2676
    Overall Length(incl.forks) 11(mm) 3665
    Body Width b1(mm) 1700
    Min.Ground Clearance m2(mm) 80
    Min.Turning Radius Wa(mm) 2240
    Wheels:Drive Side/Load Side(X=Drive Wheel)   1X+2/2
    Min.Safety Distance a(mm) 400
    Min.Main Aisle(1200×1200 self-spin/R800 Arc,200 clearance) Ast(mm) 2100
    Bi-directional Main Aisle(1200×1200 R800 Arc,200 clearance) Ast(mm) 2100
    Charging Height mm 215
    Motion

    Performance
    Drive Type   Steering Wheel
    Movement Mode   Forward/Backward,Curved Turning,Spot Rotation
    Travel Speed (Loaded/Unloaded) m/s 1.0/1.2
    Max.Gradeability(Loaded/Unloaded) % 3/5
    Positioning Accuracyuracy mm ±10
    Angle Accuracy   ±1
    Lifting Speed(Loaded/Unloaded) mm/s 180/240
    Lowering Speed (Loaded/Unloaded) mm/s Adjustable Ratio
    Lifting Height Accuracy mm ±5
    Wired Encoder
    Cylinder End Buffer
    Electronic Soft Lift/Lower
    Battery
    Performance
    Rated Voltage V 48
    Battery Capacity Ah 202
    Battery Low-temp Heating
    Charging Cycles   Full Charge and Discharge≥3000 Times
    Operating Time(Rated Condition) h 4-6
    Charging Time(1C,15-90%) h
    Charging Mode   Front Charging
    Safety
    Protection
    Front Single Laser Obstade Detection
    Front Dual Laser Obstacle Detection
    Cargo Placement Detection
    Pallet Identification
    Weighing Module   -
    Driving Recorder
    Safety Bumper Detection
    Pallet In-position Detection
    Fork Tip Photoelectric Detection
    Top Anti-collision
    Left/Right E-stop
    Tri-color Light &Buzzer
    Others 3D Laser SLAM Navigation
    10"Display
    Handle Operation   -
    Wired Handheld Controller
    Mobile APP
    RFID Reader
    Working Noise dB ≤75
    The above data is sourced from the results obtained through testing by the XGEN Robot Test Team.

    Consult With Specialist

    Get expert advice from our specialist to solve complex problems and optimize your performance efficiently.
    Contact Us

    FAQs

    • What Is FMR?

      FMR stands for Forklift Mobile Robot, which is a type of forklift-style mobile handling robot primarily used for automatic material handling and storage within warehouses.
    • What Handling Or Storage Scenarios Is FMR Suitable For?

      FMR is primarily suitable for common handling and storage scenarios in warehouses, including flat transport, production line connection, cross-floor transportation, and high-level storage.
    • How Much Weight Can FMR Carry, And How High Can It Lift?

      In past project cases of XGEN, the actual implemented maximum load was 30T, and the maximum lifting height was 13.5M.
    • What Are The Advantages Of ASRS Compared To A Traditional Warehouse?

      Compared to traditional warehouses, ASRS have the following advantages: High Space Utilization ASRS makes full use of vertical space with multi-layer shelving and automation equipment, significantly improving storage density and reducing the footprint. High Automation ASRS uses automated equipment such as stackers and conveyor systems, reducing manual labor and increasing operational efficiency and accuracy. Accurate Inventory Management With the use of WMS, ASRS can monitor inventory in real-time, optimizing stock management and reducing overstocking and stockouts. High Operational Efficiency Automated equipment can quickly complete the storage, retrieval, and handling of goods, shortening processing times and improving overall efficiency. Enhanced Safety Automation reduces manual operations, lowering accident risks. Additionally, the system has monitoring and alarm functions that further enhance warehouse safety. Cost Savings Although initial investments may be high, ASRS can significantly reduce operational costs in the long run by reducing labor, improving space utilization, and increasing operational efficiency. Strong Scalability ASRS has a modular design, making it easier to expand or adjust according to changing needs. Environment-friendly Automated equipment reduces energy consumption and carbon emissions, aligning with green and environmental standards.In summary, ASRS outperforms traditional warehouses in space utilization, automation, inventory management, operational efficiency, safety, cost savings, scalability, and environmental friendliness, making them well-suited for modern logistics needs.
    • Can ASRS Be Digitally Managed?

      Yes, ASRS can be digitally managed. Digital management is one of the core advantages of ASRS and is achieved primarily through the following methods: 1. Warehouse Management System (WMS) WMS is the core of digital management in ASRS, enabling real-time inventory monitoring, optimizing storage, managing orders, and processing data to enhance overall operational efficiency. 2. Automation Equipment Integration The automated equipment in ASRS (such as stackers and conveyor systems) is seamlessly connected with the WMS, enabling full-process automation from inbound to outbound operations, reducing manual intervention. 3. Internet of Things (IoT) Technology Through sensors and RFID technology, ASRS can monitor the location, status, and environmental conditions of goods in real-time, ensuring the accuracy and timeliness of inventory data. 4. Data Analysis and Optimization Digital management collects vast amounts of operational data, which is then analyzed to optimize inventory, predict demand, and improve processes, thus increasing warehouse efficiency and reducing costs. 5. Cloud Computing and Big Data Cloud computing and big data technologies support the digital management of ASRS by providing powerful data storage, processing, and analysis capabilities, enabling remote monitoring and management. 6. Artificial Intelligence (AI) and Machine Learning AI and machine learning technologies can be applied to demand forecasting, route optimization, and inventory management, further enhancing the intelligence of the warehouse. 7. Visualization and Real-Time Monitoring Digital management provides visual interfaces and real-time monitoring features, allowing managers to keep track of warehouse status at any time and address issues promptly.
