    Multi-directional Reach Truck FMR with 360° Omnidirectional Drive

    Multi-directional Reach Truck FMR with 360° Omnidirectional Drive

    Multi-directional Reach Truck High-Level Narrow Aisle Storage logistics
    • Product Introduction
    • Product Parameters

    The Multi-directional Reach Truck FMR is a model with patented product technology of “XGEN Robot Intelligent”. It features 360 ° omnidirectional movement, and the fork can lift to the required height while moving and position the load precisely. This allows the vehicle to turn in narrow aisles, thus greatly saving floor space and enabling intensive shelving storage. The maximum lifting height reaches 10,000 mm, which meets the demand for high-level storage.

    Features

    • Drive in full directions
    • Multiple Navigation, Safe and Reliable
    • Custom Deployment, Smart and Efficient
    • Integrated Storage & Distribution, Multiple Scenarios
    • High Position Stacking, Increase Storage Capacity
    TECHNICAL PARAMETERS                                                                                                            ●   Standard  ○  Optional   -Not available
    Basic

    Parameters
    Model   No. X5-MR10 M5-MR15
    Load Capacity kg 1000  1500
    Load Center Distance c(mm) 600  600
    Weight(incl.battery) kg 3175(5.5m Mast) 3175(8m Mast)
    Fork L×W×H 16*e*s(mm) 1170*132*45 1170*132*45
    Fork Outside Spacing b5(mm) 478-818 478-840
    Forward Reach Distance 14(mm) 550  550
    Max.Lifting Height h2(mm) 5500(standard)/6000/6500/7000/7500/8000/8500/9000/9500
    Mast Lowered Height h1(mm) 2890/3060/3225/3390/3560/3720/3890/4050/4220/4385
    Max.Vehide Height h1'(mm) 2321  2321
    Overall Length (incl.fork 1200) I1(mm) 2580  2450
    Body Width b1(mm) 1880  2050
    Min.Ground Clearance m2(mm) 50  65
    Min.Turning Radius Wa(mm) 1820  1730
    Wheels:Drive/Load (X=Drive Wheel)   2X12 2X/2
    Min.Safety Distance a(mm) 400  400
    Min.Turning Aisle Width(1200×1200 along fork) mm 3360  3270
    Stacking Aisle Width(1200×1200 along fork,200 clearance) mm 2980  2850
    Charging Height mm 200  200
    Drive Type   Dual Steering Wheel Drive Dual Steering Wheel Drive
    Movement Mode   Omni-directional Omni-directional
    Travel Speed(Loaded/Unloaded) m/s 0.8/1.2 0.8/1.2
    Motion

    Performance
    Max.Gradeability(Loaded/Unloaded) % 3/5 3/5
    Positioning Accuracyuracy mm ±10 ±10
    Angle Accuracy ° ±1 ±1
    Lifting Speed(Loaded/Unloaded) mm/s 280/320 280/320
    Lowering Speed (Loaded/Unloaded) mm/s 320/250 320/250
    Lifting Height Accuracy mm ±5 ±5
    Wired Encoder
    Cylinder End Buffer
    Electronic Soft Lift/Lower
    Rated Voltageoltage V 48  48
    Battery Capacityacity Ah 320  320
    Battery Low-temp Heating
    Battery
    Performance
    Charging Cycles   Full Charge and Discharge≥3000 Times Full Charge and Discharge≥3000 Times
    Operating Time(Rated Condition) h 4-6 4-6
    Charging Time(30-90%) h
    Charging Mode   Side Charging Side Charging
    Front Single Laser Obstacle Detection
    Front Dual Laser Obstacle Detection
    Cargo Placement Detection
    Safety
    Protection
    Pallet Identification
    Weighing Module   - -
    Driving Recorder
    Safety Bumper Detection
    Pallet In-position Detection
    Fork Tip Photoelectric Detection
    Top Anti-collision
    Left/Right E-stop
    Tri-color Light &Buzzer
    Laser SLAM Navigation
    Laser Reflector
    Visual SLAM Hybrid Navigation
    Others 10"Display
    Handle Operation   - -
    Wired Controller
    Mobile APP
    RFID Reader
    Working Noise dB ≤75 ≤75
    The above data is sourced from the results obtained through testing by the XGEN Robot Test Team.

    Consult With Specialist

    Get expert advice from our specialist to solve complex problems and optimize your performance efficiently.
    Contact Us

    FAQs

    • What Is FMR?

      FMR stands for Forklift Mobile Robot, which is a type of forklift-style mobile handling robot primarily used for automatic material handling and storage within warehouses.
    • What Handling Or Storage Scenarios Is FMR Suitable For?

      FMR is primarily suitable for common handling and storage scenarios in warehouses, including flat transport, production line connection, cross-floor transportation, and high-level storage.
    • How Much Weight Can FMR Carry, And How High Can It Lift?

      In past project cases of XGEN, the actual implemented maximum load was 30T, and the maximum lifting height was 13.5M.
    • What Are The Advantages Of ASRS Compared To A Traditional Warehouse?

      Compared to traditional warehouses, ASRS have the following advantages: High Space Utilization ASRS makes full use of vertical space with multi-layer shelving and automation equipment, significantly improving storage density and reducing the footprint. High Automation ASRS uses automated equipment such as stackers and conveyor systems, reducing manual labor and increasing operational efficiency and accuracy. Accurate Inventory Management With the use of WMS, ASRS can monitor inventory in real-time, optimizing stock management and reducing overstocking and stockouts. High Operational Efficiency Automated equipment can quickly complete the storage, retrieval, and handling of goods, shortening processing times and improving overall efficiency. Enhanced Safety Automation reduces manual operations, lowering accident risks. Additionally, the system has monitoring and alarm functions that further enhance warehouse safety. Cost Savings Although initial investments may be high, ASRS can significantly reduce operational costs in the long run by reducing labor, improving space utilization, and increasing operational efficiency. Strong Scalability ASRS has a modular design, making it easier to expand or adjust according to changing needs. Environment-friendly Automated equipment reduces energy consumption and carbon emissions, aligning with green and environmental standards.In summary, ASRS outperforms traditional warehouses in space utilization, automation, inventory management, operational efficiency, safety, cost savings, scalability, and environmental friendliness, making them well-suited for modern logistics needs.
    • Can ASRS Be Digitally Managed?

      Yes, ASRS can be digitally managed. Digital management is one of the core advantages of ASRS and is achieved primarily through the following methods: 1. Warehouse Management System (WMS) WMS is the core of digital management in ASRS, enabling real-time inventory monitoring, optimizing storage, managing orders, and processing data to enhance overall operational efficiency. 2. Automation Equipment Integration The automated equipment in ASRS (such as stackers and conveyor systems) is seamlessly connected with the WMS, enabling full-process automation from inbound to outbound operations, reducing manual intervention. 3. Internet of Things (IoT) Technology Through sensors and RFID technology, ASRS can monitor the location, status, and environmental conditions of goods in real-time, ensuring the accuracy and timeliness of inventory data. 4. Data Analysis and Optimization Digital management collects vast amounts of operational data, which is then analyzed to optimize inventory, predict demand, and improve processes, thus increasing warehouse efficiency and reducing costs. 5. Cloud Computing and Big Data Cloud computing and big data technologies support the digital management of ASRS by providing powerful data storage, processing, and analysis capabilities, enabling remote monitoring and management. 6. Artificial Intelligence (AI) and Machine Learning AI and machine learning technologies can be applied to demand forecasting, route optimization, and inventory management, further enhancing the intelligence of the warehouse. 7. Visualization and Real-Time Monitoring Digital management provides visual interfaces and real-time monitoring features, allowing managers to keep track of warehouse status at any time and address issues promptly.
